Camper Van Electrical System Planner: Solar, Battery, Wiring

Plan your 12V/24V camper electrical system: solar, battery bank, inverter, cable sizing and fuses in one planner. With wiring diagram. Free.

System

Choose your voltage, battery type and charging sources

What do Wh, Ah, Wp and MPPT mean?
  • Wh (watt-hour): how much power you use or generate in a day. 1000 Wh is 1 kWh, as on your energy bill.
  • Ah (amp-hour): how much the battery can store. 100 Ah at 12 volts is about 1200 Wh.
  • Wp (watt peak): what a solar panel delivers in full sun; on an ordinary day it is less.
  • A (amp): how much current runs through a cable. The fuse and the cable size follow from it.
  • mm²: the cross-section of a cable's copper core; the higher the number, the thicker the cable.
  • MPPT (Maximum Power Point Tracking): the type of charge controller that gets the most out of your solar panels.
  • LiFePO4 (lithium iron phosphate): the usual lithium battery in a camper.
  • DC-DC charger: charges your leisure battery from the alternator while the engine runs.
  • DC and AC: direct current from the battery (12 or 24 volts) and alternating current as at home (230 volts), made by the inverter.

Quick start

Choose a starting profile and customize it to your situation.

Cable unit

System voltage

Battery type

LiFePO4 is lighter, lasts longer and can be discharged deeper. AGM is cheaper but heavier and less efficient.

Battery size

The planner works out the battery: your daily consumption times the number of days without charging, divided by what you may draw from the battery (lithium 80 %, AGM 50 %), rounded up to the smallest common bank. The heaviest device sets a lower limit.

Days without charging

How many days do you want to go without charging? More days = larger battery.

days

How do you use the van?

My Camper uses this: there you see whether the battery lasts this long in the hardest season you tick.

Which seasons do you travel in?

Winter is off by default. Tick it if you also want to go away in December; December then becomes the measure.

Charging sources

Without a charging source (solar, alternator or shore power) you rely entirely on your battery. You can continue, but consider adding at least one.

Your plan so far

As soon as you add appliances, this shows how much power you use per day and how large your battery needs to be.

Devices
nothing selected yet
Battery
Lithium (LiFePO4) · 12V · calculated
Solar panels
not in this installation
Charge controller
not in this installation
Charger on the engine (DC-DC)
not in this installation
Inverter
not in this installation
Shore power charger
not in this installation
Basics
Main switch · Two busbars
Days without charging
2

Still to do

Consumption · Components · Results

How does the Electrical Planner work?

The Electrical Planner combines all your calculations in one clear flow.

Consumption as starting point

The Electrical Planner starts with your consumption profile. By entering your appliances, their wattage and daily usage hours, we calculate your daily energy consumption in Wh. This is the basis for all further calculations.

Integrated calculations

Based on your consumption, the tool automatically calculates: required battery capacity (accounting for depth of discharge and autonomy days), recommended inverter (if you use 230V), a suitable MPPT charge controller (if you have solar panels), and per circuit the cable size and fuse rating. These are guideline values based on your input and default values.

Schema with recommendations

The result is an electrical schema with all calculated values. For each cable you see the recommended size and fuse. The battery, inverter and MPPT show their recommended capacity. You can download this schema as PNG or print it.

Assumptions and defaults

When you add a charging source, the planner starts from default values: a 200W solar panel at 4 peak sun hours per day, a 30A B2B charger at 2 driving hours per day, and 20A shore power for 4 hours per day. Each source has its own efficiency: 80% for solar (controller, cabling, panel temperature), 90% for the alternator charger and 85% for the shore charger. AC appliances count 15% heavier because the inverter loses energy. Depth of discharge (DoD) is 80% for lithium and 50% for AGM. Every default is adjustable. The cable size and fuse calculations use the same formulas as the standalone calculators.

Sizing solar panels for your camper van

The planner uses this formula to recommend solar panel wattage (Wp): Wp = (daily consumption in Wh ÷ peak sun hours) ÷ system efficiency In Northern Europe count on 3-4 peak sun hours (PSH) per day on a yearly average. Southern Europe gives 5-6 PSH. A peak sun hour equals one hour at 1000 W/m² irradiance, the standard test condition for panel ratings. System efficiency typically lands at 70-80% (losses in MPPT charge controller, cables and battery). Example: 1500 Wh per day consumption ÷ 4 PSH ÷ 0.75 = about 500 Wp of solar needed for an average European summer day. For winter autonomy count on 1-2 PSH, which doubles the required panel size. The Electrical Planner factors all this in and outputs the recommended panel wattage, matching MPPT charge controller current and minimum cable cross-section from panel to controller.

Frequently asked questions

Does the Electrical Planner replace the individual calculators?

No, the Electrical Planner combines the calculations from the cable calculator, fuse calculator, battery calculator, inverter calculator and MPPT calculator into one flow. For detailed calculations per component, you can still use the individual tools.

How accurate are the calculations?

The calculations provide a good guideline but are not a substitute for professional advice. The tool uses standard values for cable resistance, fuse derating and solar yield. When in doubt, always consult a professional.

Can I use the schema for vehicle inspection?

The schema is a simplified block diagram, not a technical installation drawing. It can help with planning, but for official vehicle inspection you may need a more detailed schema that meets relevant standards.

Why does the planner recommend a larger battery than expected?

The battery bank is calculated for worst-case: multiple days without charging. Additionally, depth of discharge is factored in (80% for LiFePO4, 50% for AGM). The scenario bar chart shows how much less you need with charging.

Can I use the diagram to build myself?

The diagram is a planning aid, not an installation drawing. It gives guideline values for cable sizes, fuses and components, calculated from your input and default values. Always have the final installation checked by a professional.

How do I connect multiple batteries in parallel?

Use the diagonal method: connect the main positive cable to the first battery and the main negative cable to the last battery. This equalises resistance for each battery so they wear evenly. Do not connect both main cables to the same battery.

Where should the shunt be placed?

The shunt must be the only connection between the battery negative terminal and the rest of the system. All negative cables (from MPPT, DC-DC charger, inverter, consumers) go to the negative busbar, not directly to the battery. Only then can the battery monitor measure all consumption and charging.

How thick should the earth cable be?

The cable from the negative busbar to the chassis (earth) should be at least as thick as your thickest positive cable. If you have an inverter, its earth terminal must also be connected to the chassis with a separate cable.

Can my inverter and 12V consumers run simultaneously?

Yes, but watch the total current. The main fuse protects the cable from battery to busbar. When your inverter runs at full power and all 12V consumers are on, the main fuse and cable must handle this total. The planner calculates this automatically.

What type of RCD do I need with an inverter?

Use a Type B RCD with an inverter. Standard Type A RCDs may not respond correctly to the DC component that some inverters produce. A Type B detects both AC and DC leakage currents, making it safer for camper installations with an inverter.

How many solar panels do I need for my camper van?

Rule of thumb: divide daily consumption (in Wh) by 3 to get required solar wattage in Wp for an average European summer. At 1000 Wh per day that means about 330 Wp of panels. For winter or full-time use, double it. The planner calculates this precisely based on your consumption profile and chosen peak sun hours.

What are peak sun hours (PSH) and which value should I use?

A peak sun hour is one hour at 1000 W/m² irradiance (the standard test condition for panel ratings). For Northern Europe count on roughly 3 PSH yearly average, 4-5 PSH in summer and 1-2 PSH in winter. Spain or Portugal: 5-6 PSH. For pan-European travel, 3 PSH is a safe planning value. The Electrical Planner lets you set this per charging source.

Which MPPT charge controller matches my solar panels?

MPPT current must match panel wattage ÷ system voltage, with about 20% headroom. 200 Wp on a 12V system: 200 ÷ 12 = 17A, so a 20A MPPT. 400 Wp on 12V: a 30A controller. Switching to 24V lets you size the controller smaller for the same wattage. The planner calculates this automatically.

The Electrical Planner is a planning aid for your installation. Always have your final result checked by a professional.
